ES70 swing system door
Door System
※ Description
◇ Original sheet of automotive grade homogeneous tempered glass
The impact resistance reaches over 125MPa.
◇ Opening method
Flexible single open and double open modes, with internal and external handle configurations, and a lock cylinder that can be used 200000 times without damage.
◇ Die cast corner code
Adopting the patented design of die-casting corner codes to meet the needs of corner connections at different angles, the surrounding injection molding process enhances the airtightness and water tightness of corner connections.
◇ Low threshold design
The threshold height is ≤ 2CM, with multiple sealing treatments for the threshold, and the highest water and air tightness performance according to national standards.
※ Performance Parameter
Heat Preservation
8Level
Soundproof
3Level
Airtight
8Level
Watertight
6Level
Wind Load Resistance
9Level
※ Technical Parameter
| Frame thickness | Frame visual surface | Fan visual surface | Hardware configuration | Insulation strip | Glass configuration |
| 70mm | 40mm | 110.5mm | GU+SIEGENIA hardware | 33mm | San Bo |
